ELECTRIC ACTUATOR
DETAIL
Pic
Item
Voltage
Fluid
Fluid temp
Valve size
Valve material
Mounting dimensions
Max. torque
Valve type
Control method
Item
Voltage
AC24V AC110V AC220V Fluid
Air Oil Gas Water Chem. Steam Vacuum Other Fluid temp
0~50℃ 0~80℃ 0~180℃ Others Valve size
DN6 1/8" DN8 (1/4") DN10 (3/8") Valve material
PVC SS316 Others Mounting dimensions
ISO5211 F03 F05 Max. torque
10 N.M． Valve type
2-PC ball valve - thread PVC ball valve Others Control method
Basic type ON-OFF
Item
Voltage
DC24V AC24V AC110V AC220V Fluid
Air Oil Gas Water Chem. Steam Vacuum Other Fluid temp
0~50℃ 0~80℃ Others Valve size
DN6 1/8" DN8 (1/4") DN10 (3/8") DN15 (1/2") DN20 (3/4") DN25 (1") DN35(1-1/4") DN40(1-1/2") DN50 (2") Valve material
PVC Cast iron SS316 SS304 Others Mounting dimensions
ISO5211 F03 F04 F05 F07 Max. torque
35 N.M． Valve type
2-PC ball valve - thread 2-PC ball valve - flange 3-PC ball valve 3 way ball valve -thread 3 way ball valve -flange PVC ball valve butterfly valve Others Control method
Basic type ON-OFF Basic type Modulating
Item
Voltage
DC24V AC24V AC110V AC220V Fluid
Air Oil Gas Water Chem. Steam Vacuum Other Fluid temp
0~50℃ 0~80℃ 0~180℃ Others Valve size
DN6 1/8" DN8 (1/4") DN10 (3/8") DN15 (1/2") DN20 (3/4") DN25 (1") DN35(1-1/4") Valve material
PVC Cast iron SS316 SS304 Others Mounting dimensions
ISO5211 F05 F07 Max. torque
45 N.M． Valve type
Control method
Basic type ON-OFF Basic type Modulating
Item
Voltage
DC24V AC110V AC220V Fluid
Air Oil Gas Water Chem. Steam Vacuum Other Fluid temp
0~50℃ 0~80℃ 0~180℃ Others Valve size
DN6 1/8" DN8 (1/4") DN10 (3/8") DN15 (1/2") DN20 (3/4") DN25 (1") DN35(1-1/4") Valve material
PVC Cast iron SS316 SS304 Others Mounting dimensions
ISO5211 F03 F04 F05 Max. torque
35 N.M． Valve type
2-PC ball valve - thread 2-PC ball valve - flange 3-PC ball valve 3 way ball valve -thread 3 way ball valve -flange PVC ball valve butterfly valve Others Control method
Basic type ON-OFF
Item
Voltage
DC24V AC24V AC110V AC220V Fluid
Air Oil Gas Water Chem. Steam Vacuum Other Fluid temp
0~50℃ 0~80℃ 0~180℃ Others Valve size
DN15 (1/2") DN20 (3/4") DN25 (1") DN35(1-1/4") DN40(1-1/2") DN50 (2") DN80 (3") Valve material
PVC Cast iron SS316 SS304 Others Mounting dimensions
ISO5211 F04 F05 F07 Max. torque
50 N.M． Valve type
Control method
Basic type ON-OFF
Item
Voltage
DC24V AC24V AC110V AC220V Fluid
Air Oil Gas Water Chem. Steam Vacuum Other Fluid temp
0~50℃ 0~80℃ 0~180℃ Others Valve size
DN15 (1/2") DN20 (3/4") DN25 (1") DN35(1-1/4") DN40(1-1/2") DN50 (2") DN65(2-1/2") DN80 (3") Valve material
PVC Cast iron SS316 SS304 Others Mounting dimensions
ISO5211 F03 F04 F05 F07 Max. torque
50 N.M． Valve type
2-PC ball valve - thread 2-PC ball valve - flange 3-PC ball valve 3 way ball valve -thread 3 way ball valve -flange PVC ball valve butterfly valve Others Control method
Basic type ON-OFF Basic type Modulating
Item
Voltage
DC24V AC110V AC220V Fluid
Air Oil Gas Water Chem. Steam Vacuum Other Fluid temp
0~50℃ 0~80℃ 0~180℃ Others Valve size
DN15 (1/2") DN20 (3/4") DN25 (1") DN35(1-1/4") DN40(1-1/2") DN50 (2") DN65(2-1/2") DN80 (3") Valve material
PVC Cast iron SS316 SS304 Others Mounting dimensions
ISO5211 F03 F04 F05 F07 Max. torque
70 N.M． Valve type
2-PC ball valve - thread 2-PC ball valve - flange 3-PC ball valve 3 way ball valve -thread 3 way ball valve -flange PVC ball valve butterfly valve Others Control method
Basic type ON-OFF Basic type Modulating
Item
Voltage
DC24V AC24V AC110V AC220V AC220V 3φ AC380V 3φ AC440V 3φ Fluid
Air Oil Gas Water Chem. Steam Vacuum Other Fluid temp
0~50℃ 0~80℃ 0~180℃ Others Valve size
DN35(1-1/4") DN40(1-1/2") DN50 (2") DN65(2-1/2") DN80 (3") DN100(4") DN125 (5") Valve material
PVC Cast iron SS316 SS304 Others Mounting dimensions
ISO5211 F07 Max. torque
150 N.M Valve type
2-PC ball valve - thread 2-PC ball valve - flange 3-PC ball valve 3 way ball valve -thread 3 way ball valve -flange PVC ball valve butterfly valve Others Control method
Basic type ON-OFF Basic type Modulating
