- Drawing
- Specification
| MODEL | PIPE SIZE | CV | ORIFICE | FLUID TEMP. (ºC) |
Operating Pressure kgf-cm2 (bar) | Dimension (mm) |
Weight (kg) |
||||||
| WATER | AIR | STEAM | LIGHT OIL | GAS | L | H | D | ||||||
| US-35F | 1-1/4" | 22 | 35mm | -5ºC~+185ºC | 1~10 | 1~10 | 1~10 | 1~10 | 200 | 189 | 48 | 10.70 | |
| US-40F | 1-1/2" | 30 | 40mm | -5ºC~+185ºC | 1~10 | 1~10 | 1~10 | 1~10 | 200 | 189 | 48 | 10.90 | |
| US-50F | 2" | 40 | 50mm | -5ºC~+185ºC | 1~10 | 1~10 | 1~10 | 1~10 | 210 | 202 | 48 | 13.20 | |
| US-65F | 2-1/2" | 68 | 65mm | -5ºC~+185ºC | 1~10 | 1~10 | 1~10 | 1~10 | 240 | 209 | 48 | 19.20 | |
| US-80F | 3" | 100 | 80mm | -5ºC~+185ºC | 1~10 | 1~10 | 1~10 | 1~10 | 300 | 228 | 48 | 27.00 | |
| US-100F | 4" | 175 | 100mm | -5ºC~+185ºC | 1~10 | 1~10 | 1~10 | 1~10 | 340 | 244 | 48 | 38.70 | |
- Material
| PARTS | Coil | Tube | Spring | Core | Plug | Piston Spring | Piston | Piston Plug | Valve Body |
| MATERIAL | Special Copper Wire (H Class) |
Stainless Steel | Stainless Steel | Stainless Steel | PTFE | Stainless Steel | Stainless Steel | PTFE | Cast Iron (FC-20) |
- Description
- US-F series is multiplex, pilot operated piston, conductive, and normally close (NC) 2/2 solenoid valve
- Availability of fluid: water, air, light oil
- Cautions
- Minimum pressure to operate: over 0.5kgf-cm2
- Before installation depressurize the piping system and clean internally.
- For the protection of the equipment install a strainer or filter suitable for the service involved in the inlet side as close to the solenoid valve as possible.
- AC voltage tolerance: +/- 10%; DC voltage tolerance: +/- 1%
- All standard solenoid valve MUST be mounted vertically upright.
- Not suitable for fluid as below:
- Liquid status when it is at high temperature; solid status when it is cool.
- Corrosive fluid
- Viscosity over 20cst
